EverSolo DMP-A8 Network Streamer

Description EverSolo DMP-A8 Network streamer with bluetooth 5.0 aptX HD EverSolo DMP-A8 network streamer with AKM AK4191EQ AK4499EX dual mono DAC and resolution up to 32bit 768kHz PCM, DSD512 MQA support, 6″ high definition LCD touch screen display and Bluetooth 5.0 aptX HD The touch screen display is integrated into the aluminum chassis and allows for practical and intuitive use where it is possible to access all the player's options and information. Its onboard 4GB DDR 64GB eMMC storage lets you store music locally, and there's a slot compatible with a 2TB M.2280 NVME 4 SSD, which can be installed without removing the cover. Two high-precision clock oscillators, one operating at 45.1584MHz, and one at 49.152MHz (corresponding to the frequencies of 44.1KHz and 48KHz and the relative multiples of sampling frequencies) effectively eliminate jitter, ensuring conversion and decoding of audio signals with very high accuracy and precision. It uses two distinct power supplies: one for the digital section, and one for the analogue section. The linear power supply consists of a multi-winding toroidal transformer, while the very high quality switching power supply is for the digital and IT control sections. Connectivity It has a third generation XMOS 316 USB interface. for perfect reception and decoding of the USB audio stream. It supports audio streams up to PCM 32bit 768kHz, DSD up to DSD512 and MQA. Optical ports (coaxial and Toslink) support DSD 64 (DoP) and 192-bit PCM 24. When used as a DAC it offers many digital connections: 2 coaxial inputs, 2 optical inputs and also USB type B to connect PCs and mobile devices (Smartphones and Tablets), whileand used as a preamplifier, it supports RCA and XLR analog inputs. It is possible to connect it directly to active speakers or to power amplifiers through the pre-amplified RCA and balanced XLR analogue outputs. Used as a digital transport, it can be connected to external DACs through the I2S HDMI, USB Audio, Optical Toslink and RCA 75 Ohm digital coaxial connections. Bluetooth 5.0 uses a Qualcomm QCC5125 chip that supports SBC, AAC, aptX, aptX LL, aptX HD and LDAC high-definition transmission codecs. Technical Specifications Display: 6 inch LCD touch screen Internal memory: 4GDDR4 64GeMMC DAC: AKM AK4191EQ AK4499EX Audio processor: XMOS XU316 Operational amplifier (op-amp chip): OPA1642 Power Supply: High quality, low noise, toroidal linear and switching power supplies HDD Bay: M.2 NVME 3.0 2280 protocol, up to 4TB (compatible with M.2 NVME 4.0 2280 SSD) (SSD optional) USB A port: 2 USB 3.0 ports DAC audio decoding: supports stereo up to DSD512, PCM 768KHz 32Bit, MQA (Master Quality Authenticated) Supported music services: Internet radio (TuneIn Radio and Audials Play), Tidal, Spotify, Qobuz, Highresaudio, Amazon, Apple Music, Deezer, Napster, KKBOX, WebDAV, UPnP Streaming Technologies: Air Play, DLNA, Roon Ready, Spotify, Tidal Connect, Qobuz Connect, etc. ARC HDMI: Supports up to 192KHz 24-bit stereo PCM Preamplifier Analog Input: XLR balanced, RCA unbalanced. Maximum gain 10dB Optical (Toslink)/Coaxial (Coaxial) Output: Supports up to 192KHz 24-bit stereo PCM, DSD64 allowed Device control methods: mobile application control, touch screen control CD ripping function Connections Wi-Fi: dual band 2.4G 5G Ethernet: RJ45 (10/100/1000Mbps) System compatibility: Windows (7, 10), Mac, Android, IOS Audio Compatibility: Stereo DSD512, PCM 768 KHz 32 bit, MQA Multi-channel HDMI audio output: native DSD64, raw multi-channel: PCM 192KHz DIGITAL AUDIO INPUTS Bluetooth 5.0 codecs supported: SBC, AAC, aptX, aptX LL, aptX HD, LDAC USB Type-C input: USB compatible audio system: Windows（10,11), Mac, Android, iOS, support up to DSD512 Stereo, PCM 768KHz 32Bit Optical Input (Toslink): Supports up to 192KHz 24-bit stereo PCM, DSD64 allowed Coaxial Input (Coaxial): Supports up to 192KHz 24bit stereo PCM, DSD64 allowed DIGITAL AUDIO OUTPUTS Bluetooth 1x coaxial 1x Optical Toslink 1xHDMI 2x USB-A 3.0 ANALOGUE AUDIO OUTPUTS Unbalanced stereo RCA Balanced stereo XLR Integrated music services: Tidal, Qobuz, Highresaudio, Amazon, WebDAV, UPnP Compatible streaming services: Air Play, DLNA, Roon Ready, Spotify, Tidal Connect, Qobuz Connect etc. Supported network protocol: NFS/SMB v1-v2-V3/UPnP Analog output specifications BALANCED XLR OUTPUT Output Level: 4.2V Frequency response: 20Hz ~ 20kHz (±0,25dB) Tonal range (DNR): >128 dB Signal-to-noise ratio (SNR): >128 dB Harmonic distortion factor with noise (THD N): <0,00009%(-120dB) @No-wt Crosstalk: > -121dB UNBALANCED RCA OUTPUT Output Level: 2,1V Frequency response: 20Hz ~ 20kHz (±0,25dB) Tonal range (DNR): >125 dB Signal-to-noise ratio (SNR): >125 dB Harmonic distortion factor with noise (THD N): <0,00010%(-119dB)@A-WT Crosstalk: > -121dB Generali Power supply: AC 110~240V 50/60Hz Nominal power: 16 W Dimensions (D x W x H): 388mm x 248mm x 90mm Color: Black In the box: EverSolo DMP-A8, power cable, remote control, screwdriver, user manual. Support FLAC, Native App, HD Hi-Res Audio, Spotify, Qobuz, Wi-Fi, MQA
